The smartest, compact soundbar with MultiBeam™ surround sound

For Bulk Enquiry: Click Here

Beautiful Sound That Speaks To You

Elegant, dynamic and powerful. The Harman Kardon Citation MultiBeam™ 700 delivers full surround sound to your TV without the need for extra speakers and wires. As a standalone soundbar, it projects rich audio to every corner of the room. Plus, you can control the experience using just your voice, with help from the Google Assistant. When paired with the rest of the Citation range, the Citation MultiBeam 700 can also operate as a center channel to create the ultimate home theater setup for full, detailed surround sound. Enjoy more than 300 music streaming services with the convenience of AirPlay and Chromecast built-in. Experience beautiful sound, no matter how you listen.

Item# HKCITAMB700BLKAS

General Specifications

Note CITATION MULTIBEAM 700 is in compliance with European Commission Regulation (EC) No 1275/2008 and (EU) No 801/2013.
Power consumption:- Yes
Off Mode N/A
Standby N/A
Network Standby* 2.0 Watts
Time to networked standby 18 minutes *
Networked standby in the condition of any wireless connection of the device is activated, if no provide any audio or video signal to the device, it will automatically into networked standby mode in 18 minutes. Any audio or video recover will bring device from standby to operation mode.

Audio Specifications

Transducer 2 x 25mm tweeter, 5 x 50mm woofer
Output power 210W RMS
Signal-to-noise ratio >80dB

Dimensions

Dimensions (W x H x D) 790 x 65 x 130mm (31.1" x 2.6" x 5.1")
Weight: 3.7kg (8.1lb) Yes

Control and Connection Specifications

Bluetooth® version 4.3
Bluetooth transmitter frequency range 2402 – 2480MHz
Bluetooth transmitter power <10dBm
Bluetooth transmitter modulation GFSK,π/4 DQPSK, 8DPSK
Wireless network 802.11 a/b/g/n/ac (2.4GHz/5GHz)
2.4G Wi-Fi transmitter frequency range 2412 – 2472MHz (2.4GHzISM Band, USA 11 Channels, Europe and others 13 Channels)
2.4G Wi-Fi transmitter power <20dBm
2.4G Wi-Fi modulation DBPSK, DQPSK, CCK, QPSK, BPSK, 16QAM, 64QAM
5G Wi-Fi transmitter power <23dBm
5G Wi-Fi modulation QPSK, BPSK, 16QAM, 64QAM, 256QAM
5G Wi-Fi transmitter frequency range 5.15 - 5.35GHz, 5.470 - 5.725GHz, 5.725 - 5.825GHz

Battery

Power Supply 100-240V~50/60Hz
Power consumption in sleep mode <2.0 Watts

Notification

Google, Google Play, Chromecast, Chromecast built-in, Google Home and other related marks and logos are trademarks of Google Inc. Yes
Chromecast built-in may require subscription(s). -
The Bluetooth® word mark and logos are registered trademarks owned by Bluetooth SIG, Inc. and any use of such marks by HARMAN International Industries, Incorporated is under license. Other trademarks and trade names are those of their respective owners. The Wi-Fi CERTIFIED Logo is certification marks of the Wi-Fi Alliance. -
* Requires compatible device. Availability and performance of certain other features and services are service, device and network-dependent and may not be available in all areas; subscription(s) may be required, and additional terms, conditions and/or charges may apply. -
Manufactured under license from Dolby Laboratories. Dolby and the double-D symbol are trademarks of Dolby Laboratories. -
The terms HDMI, the HDMI logo, and High-Definition Multimedia Interface are trademarks or registered trademarks of HDMI Licensing LLC in the United States. -
Features, specifications and appearance are subject to change without notice. -
Click here for a complete list of all specs for this product

Spec Sheet (English)

English 651 KB
  • 1 x Citation MultiBeam™ 700
  • 1 x Power cable
  • 1 x Quick-start guide
  • 1 x Warranty sheet
  • 1 x Safety sheet
product box
{"totalSize":3,"done":true,"searchRecords":[{"attributes":{"type":"Knowledge__kav","url":"/services/data/v45.0/sobjects/Knowledge__kav/ka25d000000XjJaAAK"},"Title":"HK Citation: Cleaning FAQ","Id":"ka25d000000XjJaAAK","ArticleNumber":"000016804","Question__c":"How to properly clean the fabric around the speakers","Process__c":"Daily Care instructions for Citation speakers fabric (wool)\nDaily care and immediate stain removal will ensure that your Harman/Kardon Citation wool upholstery will keep looking good for many years.\nNever use undiluted cleaning agents, bleaching agents, ammonia or soap intended for hard surfaces, as this may damage the fabric and Citation speaker itself!\n\nMany types of stain can be removed using warm water with a microfiber cloth (not too wet).\nStain removal guide\nIf you act quickly with any stains on your Citation device then it is not difficult to remove or avoid any spill/stains.\nHere is how to do it.\n\nFirst, soak up the liquid with an absorbent napkin or Microfiber cloth.\nFor dried stains use a spoon to roughen the surface.\nTo avoid the stain spreading further start from the edge of the stain working towards the middle.\nWARNING!\nBe careful when using solvents, because these could dissolve the upholstery material beneath.\nRegular and normal cleaning\nVacuum frequently every week is the best way to keep the Harman/Kardon Citation fabric intact or use a varm wet Microfiber cloth.\nWhen using a vacuum cleaner, remember to set the power to half which is most appropriated to use for Citation devices (this will not harm the design or fabric).\n \n\n\nGeneral information\nThese tips are purely recommendations and cannot guarantee 100% stain removal on your Harman/Kardon Citation device.\nIn all cases, we recommend contacting a professional cleaning company, particularly for bigger stains and for thorough cleaning the wool fabric and speaker.\nHARMAN do not have any recommended companies or partners to redirect any customers too.\n\nFor furter information we advise visiting the fabric company called KVADRAT by clicking on these links below:\nhttps://kvadrat.dk/care-and-maintenance/upholsteries\nhttps://kvadrat.dk/download/media/download-section/relatedfiles/kvadrat-maintenance-manual-2016-uk.pdf \n\nThere are a lot of information about the fabric we are using and you can contact them for further information.","Answer__c":"Daily Care instructions for Citation speakers fabric (wool)\nDaily care and immediate stain removal will ensure that your Harman/Kardon Citation wool upholstery will keep looking good for many years.\nNever use undiluted cleaning agents, bleaching agents, ammonia or soap intended for hard surfaces, as this may damage the fabric and Citation speaker itself!\n\nMany types of stain can be removed using warm water with a microfiber cloth (not too wet).\nStain removal guide\nIf you act quickly with any stains on your Citation device then it is not difficult to remove or avoid any spill/stains.\nHere is how to do it.\n\nFirst, soak up the liquid with an absorbent napkin or Microfiber cloth.\nFor dried stains use a spoon to roughen the surface.\nTo avoid the stain spreading further start from the edge of the stain working towards the middle.\nWARNING!\nBe careful when using solvents, because these could dissolve the upholstery material beneath.\nRegular and normal cleaning\nVacuum frequently every week is the best way to keep the Harman/Kardon Citation fabric intact or use a varm wet Microfiber cloth.\nWhen using a vacuum cleaner, remember to set the power to half which is most appropriated to use for Citation devices (this will not harm the design or fabric).\n \n\n\nGeneral information\nThese tips are purely recommendations and cannot guarantee 100% stain removal on your Harman/Kardon Citation device.\nIn all cases, we recommend contacting a professional cleaning company, particularly for bigger stains and for thorough cleaning the wool fabric and speaker.\nHARMAN do not have any recommended companies or partners to redirect any customers too.\n\nFor furter information we advise visiting the fabric company called KVADRAT by clicking on these links below:\nhttps://kvadrat.dk/care-and-maintenance/upholsteries\nhttps://kvadrat.dk/download/media/download-section/relatedfiles/kvadrat-maintenance-manual-2016-uk.pdf \n\nThere are a lot of information about the fabric we are using and you can contact them for further information.","ArticleType":"How_Tos__kav"},{"attributes":{"type":"Knowledge__kav","url":"/services/data/v45.0/sobjects/Knowledge__kav/ka25d000000Xqw5AAC"},"Title":"JBL LINK: Wi-Fi network not found during setup","Id":"ka25d000000Xqw5AAC","ArticleNumber":"000020171","Question__c":"Learn how to troubleshoot when you can’t connect your Google Assistant device to your home Wi-Fi network.","Process__c":"

The Checklist

\n\n

Let us walk-through a list of things needed to ensure every requirement is met.

\n\n
  1. Check your mobile device if that is able to connect to same Wireless network.
  2. Make sure you are within range of your Wireless router.
  3. Check the Wireless signal on your mobile device, does it have a weak signal then move closer to the router.
  4. Try both Wireless network bands 2.4GHz and 5GHz in case one of them are failing.\n\t
    1. You will have longer range with 2.4GHz, but less performance and most of the times a crowded network (many devices are using 2.4GHz band).
    2. You will have less interference with 5GHz and higher performance, however, the range of the 5GHz network has shorter range.
    \n\t
  5. Try using a different mobile device, if you have one.
  6. Reboot your Wireless network router and your mobile device.
\nWatch the video below for help with setting up your Google Assistant device.\n\n

\n\n

Wireless Network Extender

\n\n

Some houses or apartments can be too big for one Wireless network router to cover it all.
Let's talk about the issues that might appear with an Extender network.

\n\n
  1. Network Extenders that will help cover poor signal in your home, often results in poor connection and low speed performance.
  2. Often the Network Extender is a low budget device or not suited for having too many devices attached to it.
  3. Placement of the speaker is crucial as you can put it in a place where it could connect to either main Wireless router or the Extender, that will confuse Wireless network devices.
  4. To solve this issue, try move the speaker closer to main router or have fewer devices attached to your Wireless Extender.
  5. In addition, always use 5GHz connection between your Network extender and main router (best solution and performance).
\n\n

One Wireless Network Name (SSID)

\n\n
  1. You may have set the Wireless Network SSID (Wi-Fi network name) to one big Wireless network (With a main router + Extender(s).
  2. If the JBL LINK device is within range of both Wireless networks (Main router & Extender) then it can get confused with which one to connect to.
  3. To solve this issue, using two different name for your extended network will help with the performance of the JBL LINK Speaker and Google Assistant request.
\n\n









","Answer__c":"

The Checklist

\n\n

Let us walk-through a list of things needed to ensure every requirement is met.

\n\n
  1. Check your mobile device if that is able to connect to same Wireless network.
  2. Make sure you are within range of your Wireless router.
  3. Check the Wireless signal on your mobile device, does it have a weak signal then move closer to the router.
  4. Try both Wireless network bands 2.4GHz and 5GHz in case one of them are failing.\n\t
    1. You will have longer range with 2.4GHz, but less performance and most of the times a crowded network (many devices are using 2.4GHz band).
    2. You will have less interference with 5GHz and higher performance, however, the range of the 5GHz network has shorter range.
    \n\t
  5. Try using a different mobile device, if you have one.
  6. Reboot your Wireless network router and your mobile device.
\nWatch the video below for help with setting up your Google Assistant device.\n\n

\n\n

Wireless Network Extender

\n\n

Some houses or apartments can be too big for one Wireless network router to cover it all.
Let's talk about the issues that might appear with an Extender network.

\n\n
  1. Network Extenders that will help cover poor signal in your home, often results in poor connection and low speed performance.
  2. Often the Network Extender is a low budget device or not suited for having too many devices attached to it.
  3. Placement of the speaker is crucial as you can put it in a place where it could connect to either main Wireless router or the Extender, that will confuse Wireless network devices.
  4. To solve this issue, try move the speaker closer to main router or have fewer devices attached to your Wireless Extender.
  5. In addition, always use 5GHz connection between your Network extender and main router (best solution and performance).
\n\n

One Wireless Network Name (SSID)

\n\n
  1. You may have set the Wireless Network SSID (Wi-Fi network name) to one big Wireless network (With a main router + Extender(s).
  2. If the JBL LINK device is within range of both Wireless networks (Main router & Extender) then it can get confused with which one to connect to.
  3. To solve this issue, using two different name for your extended network will help with the performance of the JBL LINK Speaker and Google Assistant request.
\n\n









","ArticleType":"How_Tos__kav"},{"attributes":{"type":"Knowledge__kav","url":"/services/data/v45.0/sobjects/Knowledge__kav/ka25d000000XjQKAA0"},"Title":"HK Citation: Not visible as Chromecast device","Id":"ka25d000000XjQKAA0","ArticleNumber":"000033721","Question__c":"Sometimes my Chromecast enabled streaming app cannot see my Citation speaker. What should I do?","Process__c":""In certain network conditions, your speaker may not be visible from your streaming app. You can still use voice control to start & control playback.\n\nIf you wish to use your phone app to control playback, please power cycle your Citation speaker and your phone."","Answer__c":""In certain network conditions, your speaker may not be visible from your streaming app. You can still use voice control to start & control playback.\n\nIf you wish to use your phone app to control playback, please power cycle your Citation speaker and your phone."","ArticleType":"How_Tos__kav"}]}

FAQs
